Inconel 625 Lap Joint Flange
- FOB PriceUSD 1 - 1,900/Piece
- PortNingbo or Shanghai Port
- MOQ1 Piece
- Supply Ability1000 Pieces Per Day
- Payment TermsL/C,T/T,Western Union,MoneyGram
- PackagingSeaworthy plywood cases or pallets
- Delivery2 - 10 days
Quick Details
| Material: |
Inconel 625, etc
| Technics: |
Forged
| Type: |
Inconel 625 Lap Joint Flange
|
| Place of Origin: |
Zhejiang, China (Mainland)
| Head Code: |
Round
| Brand Name: | |
| Connection: |
Welding
| Shape: |
Equal
|
Packaging & Delivery
| Packaging Details: | plywood case or fumigation woodern case |
|---|---|
| Delivery Detail: | 2 - 10 days |
Description Of Inconel 625 Lap Joint Flange
Type
Size
1/2" To 48" (DN15-1200)
Wall thickness
sch10, sch20, sch30, std, sch40, sch60,
xs, sch80, sch100, etc
Standards
ASME, ASTM, DIN, JIS, etc
Material
Carbon Steel: ASTM: SA105N/A105, ASTM SA350 LF2,etc
Stainless Steel: ASTM A182 F304/304L/316/316L, etc
Alloy Steel: ASTM A182 F1/F5/F9/F11/F22/F91, Etc.
Duplex stainless steel: ASTM A182 F51/F53/F55/F60, etc
Nicke alloys: Nickel 200, Monel 400, Inconel 600/625, Incoloy 825/800,
Hastelloy C276, Hastelloy C22, Hastelloy B1/B2/B3, Alloy 20, etc
Cu-Ni: 90/10,70/30, etc
Surface treatment
Transparent oil, rust-proof black oil or hot galvanized
Applications
Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc
Inconel 625 Lap Joint Flange Or Loose Flange: Used in conjunction with a universal stub end fittings, this flange is often used to avoid issues that could arise with the alignment of bolt holes. Stub End fittings are welded to the pipe, and the lap joint flange is designed to slide over the pipe and rotate around the stub end. They are commonly used in applications where the juncture does not come in contact with the fluid or gas making them reusable, and they are also beneficial in applications keeping down expenses when exotic metals are used.
Description Of Inconel 625 Lap Joint Flange
Type
| |
Size
|
1/2" To 48" (DN15-1200)
|
Wall thickness
|
sch10, sch20, sch30, std, sch40, sch60,
xs, sch80, sch100, etc
|
Standards
|
ASME, ASTM, DIN, JIS, etc
|
Material
|
Carbon Steel: ASTM: SA105N/A105, ASTM SA350 LF2,etc
Stainless Steel: ASTM A182 F304/304L/316/316L, etc
Alloy Steel: ASTM A182 F1/F5/F9/F11/F22/F91, Etc.
Duplex stainless steel: ASTM A182 F51/F53/F55/F60, etc
Nicke alloys: Nickel 200, Monel 400, Inconel 600/625, Incoloy 825/800,
Hastelloy C276, Hastelloy C22, Hastelloy B1/B2/B3, Alloy 20, etc
Cu-Ni: 90/10,70/30, etc
|
Surface treatment
|
Transparent oil, rust-proof black oil or hot galvanized
|
Applications
|
Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc
|
Inconel 625 Lap Joint Flange Or Loose Flange: Used in conjunction with a universal stub end fittings, this flange is often used to avoid issues that could arise with the alignment of bolt holes. Stub End fittings are welded to the pipe, and the lap joint flange is designed to slide over the pipe and rotate around the stub end. They are commonly used in applications where the juncture does not come in contact with the fluid or gas making them reusable, and they are also beneficial in applications keeping down expenses when exotic metals are used.
Standard
Inconel 625
UNS
N06625
Werkstoff Nr.
2.4856
Standard
|
Inconel 625
|
UNS
|
N06625
|
Werkstoff Nr.
|
2.4856
|
Chemical Composition Of Inconel 625 Lap Joint Flange
Weight %
|
Ni
|
Cr
|
Mo
|
Nb + Ta
|
Fe
|
Ti
|
Alloy 625
|
58.0 min
|
20 - 23
|
8 -10
|
3.15 -4.15
|
5.0 max
|
0.40 max
|
C
|
Mn
|
Si
|
S
|
P
|
Al
|
Co
|
0.10 max
|
0.50 max
|
0.50 max
|
0.15 max
|
0.15 max
|
0.40 max
|
1.0 max
|
Mechanical & Physical Properties – Inconel 625
Density 8.4 g/cm3 Melting Point 1350 °C (2460 °F) Tensile Strength Psi – 135,000 , MPa – 930 Yield Strength (0.2%Offset) Psi – 75,000 , MPa – 517 Elongation 42.5 %
| Density | 8.4 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 135,000 , MPa – 930 |
| Yield Strength (0.2%Offset) | Psi – 75,000 , MPa – 517 |
| Elongation | 42.5 % |
In what applications is Inconel 625 used?
- Aircraft ducting systems
- Aerospace
- Jet engine exhaust systems
- Engine thrust-reverser systems
- Specialized seawater equipment
- Chemical process equipment
Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Inconel Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN.
In what applications is Inconel 625 used?
- Aircraft ducting systems
- Aerospace
- Jet engine exhaust systems
- Engine thrust-reverser systems
- Specialized seawater equipment
- Chemical process equipment
Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Inconel Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN.
Inconel 625 Lap Joint Flange's Packing & Shipping
1) Packing Method:
Normal packing: plastic film or bubble paper wrapped on product's surface ,protect ends with caps,
pack with wooden case or load on fumifation plywood pallet .
Custom made as customers request .
2) Shipping Way:
Usually by Sea, By Air, By Train or River-and-Sea Coordinated Transport.
As per customer's request.
Where can we find the high quality Inconel 625 Lap Joint Flange.
You can visit this website: www.yaang.com (Zhejiang Yaang Pipe Industry Co., Limited).
If any inquiry about products, please feel free to contact us sales@yaang.com
